USB Microphone
USB MicrophoneUSB MicrophoneUSB MicrophoneUSB MicrophoneUSB MicrophoneUSB MicrophoneUSB Microphone
USB Microphone
USB microphone model iSV1611 is a kind of digital microphone with USB interface, composed of measurement microphone, preamplifier, 16 bit A/D and USB interface which can be used with the Apps on smartphone, tablet or the program on PC.
Smartphone or tablet or computer will get the digital signal data through USB cable connecting with iSV1611, combining the program installed on smart device, just be a unit of digital sound level meter or real time signal analyzer can do integral measurement, statistical measurement, Octave, 1/3 Octave and FFT analysis.
Because the digital signal is from USB microphone instead of the built-in microphone on smart device, its application meet for the standard IEC 61672 Class 1 and IEC 61260 Class 1.
产品说明书获取
立刻购买
执行标准产品特点主要技术指标功能选配及应用
主要技术指标

    Model

    iSV1611

    A/D Sample Frequency

    48 kHz, 96kHz, 192kHz

    Channels

    2

    Microphone interface

    60UNS

    Electrical noise floo

    12dBA

    Acoustical noise floor

    16dBA

    Max input SPL

    >140dB

    Typical Sensitivity Level

    -28 dB (Ref. 1 V/Pa as referenced 0 dB)

    VID PID Programmable

    Yes

    USB Interface Standard

    USB2. 0, downward compatibility USB 1 蜜桃视频. 1 standard .

    Dimension

    φ20×165 (mm) (1/2", Outer diameter of protector coverφ13 蜜桃视频在线观看. 2mm).

    Weighting

    96 g


功能选配及应用


■  Precision acoustic measurements

■  Noise level  measurement
